akYtec - MU210-501 Analog Output Module
List-Price: AU$0.00
The analog output module MU110-501 has 8 analog outputs (0(4)-20 mA, 0-1(10)V). To communicate the input data to a controller, an Ethernet port and Modbus TCP are at your disposal. The module requires 24V DC input power and can operate in the temperature range between -40 and +55 °C.
- Pulse-width modulation (PWM)
- 2 bypass-capable Ethernet ports
- Support for daisy-chain wiring
- Support for Modbus TCP, MQTT, SNMP, SNTP
- Simultaneous communication with up to 4 TCP clients
- LEDs for network status diagnostics
- Support for data logging
- Built-in real-time clock
- Free of charge configurator
- Synchronous configuration update of two or more selected modules
The daisy-chain connectivity and support for Ethernet auto-bypass prevent accidental loss of communication if one of the modules unexpectedly shuts down
| General | |
|---|---|
| Power supply | 24 (10...48) V DC |
| Power consumption, max. | 5 W |
| Analog outputs | |
| Quantity | 8 |
| Type | 0(4)-20 mA, 0-1(10) V |
| Communication | |
| Interface | Dual Port Ethernet 10/100 Mbit |
| Configuration interfaces | USB 2.0 (MicroUSB), Ethernet 10/100 Mbit |
| Protocol | Modbus TCP |
| Environment | |
| Ambient temperature | -40...+55 °C |
| Storage temperature | -40...+55 °C |
| Humidity | up to 95%, non-condensing |
| IP Code | IP20 |
| Enclosure | |
| Dimensions | 42 x 124 x 83 mm |
| Weight | approx. 400 g |
| Material | plastic |
